Gear & Pulley Set

About Gear & Pulley Set

Gear & Pulley Set

For the demonstration of basic fundamentals that are quite often used in mechanisms in day to day life. The transparent, see-through construction of the models provides easy visualization and thorough understanding of the underlying concepts to the science students of higher grades. All the components used in the modules are made to very high degree of precision, exclusive feature stemming from their interchangeability. Very easy to assemble and disassemble. The modules available are:

·          Single Stage Spur Gear

·          Single Stage Spur Gear with Intermediate Gear

·          Two Stage Spur Gear

·          Three Stage Spur Gear

·          Three Speed and Reverse Gear

·          Worm Gear

·          Bevel Gear

·          Rack and Quadrant Gear Drive

·          Reversing Gear (Tumbler type)

·          Epicyclic Gear (Sun & Planet)

·          Cycloidal motion

·          Internal Rolling Gear Drive

·          Internal Gear and Pinion Drive

·          Helical Gear

·          Spiral Gear 90°

·          Spiral Gear Single Stage with Intermediate Gear

·          Herringbone Gear

·          Crank Drive to Oscillating Link

·          Crankshaft and Slider Mechanism

·          Two Crank and Linkage Drive (Variable Velocity)

·          Crank and Slotted Link Drive (Oscillator)

·          Crank and Slotted Link Drive (Variable Velocity)

·          Friction Wheel Drive (Circumference)

·          Centrifugal Mechanism and Clutch Drive

·          Friction Wheel Drive (Variable Speed)

·          Cone Clutch Drive (Single Sided)

·          Cone Clutch Drive (Two Speed)

·          Dog Clutch Drive (Single Sided)

·          Dog Clutch Drive (Two Speed)

·          Flat Belt Drive (with Tensioner)

·          Belt Drive Toothed

·          Belt Drive Single Speed

·          Belt Drive Two Stage

·          Belt Drive (Contra Rotation)

·          Belt Drive Multi Speed

·          Chain Drive (with Tensioner)

·          Geneva Drive (Maltese Cross)

·          Sliding Wedge Gear with Straight Line and Accurate Output

·          Cam with Straight Line and Level Followers

·          Face Cam Drive (Free Follower)

·          Face Cam Drive (Double Sided)

·          Oldhams Coupling

·          Differential Gear

·          Lathe Screw Cutting

·          Shaper

·          Crank and Connecting Rod

·          Four Bar Link Mechanism

·          Scotch Yoke Mechanism

·          Ellipse Tracer

·          Watt Mechanism

·          Peaucellier Linkage Drive

·          Pantograph Mechanism

·          Allen Link Motion

Hobbing
