Fully Automatic Microtome Model

Get a Price/Quote

Fully Automatic Microtome Model Specification

Core Components
Motor, Microprocessor Controller, Precision Rotary Blade Holder

Feature
Highly Efficient

Power Source
Electric

Temperature Range
-10C to +50C

Accuracy
100 %

Voltage
220-240 V AC

Model No
FAMT-2024

Measurement Range
Section thickness range 0.5 to 100 m

Capacity
250-300 specimen blocks per day

Frequency
50-60 Hz

Automation Grade
Fully Automatic

Equipment Materials
High-grade Stainless Steel, ABS Plastic

Type
Fully Automatic Microtome

Usage
Laboratory

Display Type
Digital LCD Display

Dimension (L*W*H)
450 x 320 x 310 mm

Weight
Approx. 25 kg

Blade Holder
Universal with lateral displacement

Trimming Thickness Range
1500 m

Packaging
Export Standard Carton

Section Thickness Setting
0.5 m increments

Retraction
60 m

Operating Humidity Range
10%80%

Cutting Stroke
60 mm

Specimen Feed
Automatic and Manual Modes

Emergency Stop
Available

Cutting Speed
Adjustable, 0430 mm/s

Noise Level
60 dB

Specimen Clamp
Quick-release and self-centering

Cooling System
Built-in specimen cooling

Color
White/Blue

About Fully Automatic Microtome Model

Microtome at a Glance

Motorized feed and sectioning.

Section and trimming thickness display.

Section counter.

Automatic / Manual Control.

Continous section / Single Section Control.

Fast Forward / Backward Function.

Section / Trimming change over.

Automatic memorization and recovery.

Emergency stop.

Auto retracting mechanism.

Ergonomic design.

TECHNICAL SPECIFICATION
Specifications	SSI/97	SSI/98	SSI/99
Operation	Manual	Semi Automatic	Fully Automatic
Section thickness range	0.5-60 m	0.5-100 m	0.5-100 m
Setting value increments	0.5-2m in 0.5m 2-20m in 1m 20-60m in 5m	0.5-5m in 0.5m 5-20m in 1m 20-60m in 5m 60-100m in 10m	0.5-5m in 0.5m 5-20m in 1m 20-60m in 5m 60-100m in 10m
Disposable blade	Low / High Profile	Low / High Profile	Low / High Profile
Minimum setting value	0.5m	0.5m	0.5m
Trimming thickness setting range	1-60m	1-600m	1-600m
Horizontal feed	26-28mm	28mm	28mm
Vertical specimen stroke	60mm	60mm	60mm
Specimen retraction	Optional	5-100m in 5m	5-100m in 5m
Lockable hand wheel	Yes	Yes	Yes
Microprocessor bases control system	N.A	Yes	Yes
Razor holder for knife	Optional	Optional	Optional
Safety alarm	N.A	Yes	Yes
Emergency stop	N.A	N.A	Yes

Advanced Sectioning Precision

Equipped with 0.5 m incremental thickness adjustment and a wide trimming range, the microtome guarantees highly accurate and repeatable sectioning. Its precision rotary blade holder and microprocessor controller work synchronously for consistent results, making it ideal for diverse specimen types in laboratory use.

User Safety and Convenience

The device features a quick-release, self-centering clamp for secure specimen handling and an effective emergency stop for immediate shutdown. Its built-in specimen cooling and low noise emissions ensure a comfortable and safe laboratory environment during prolonged operation.

Efficient Workflow and High Capacity

Processing up to 300 specimen blocks per day, the fully automatic microtome improves lab throughput while maintaining rigorous accuracy. The automatic and manual modes allow users to tailor operations to the task, supported by a clear digital LCD display and adjustable cutting speed.

FAQs of Fully Automatic Microtome Model:

Q: How does the Fully Automatic Microtome Model FAMT-2024 improve laboratory sectioning efficiency?

A: This microtome combines automated and manual specimen feed with adjustable cutting speed and high specimen block capacity, allowing labs to process up to 250300 samples daily with precise section thickness settings. Its advanced mechanics reduce manual effort while boosting output and accuracy.

Q: What is the process for adjusting section thickness and trimming on this microtome?

A: Operators can set section thickness in 0.5 m increments and choose a trimming thickness ranging from 1500 m using the intuitive digital LCD controls. The microprocessor ensures precise replication for each cut within the designed measurement range, enhancing reproducibility across specimens.

Q: When should I use the built-in specimen cooling function?

A: The specimen cooling system is recommended for applications involving heat-sensitive tissue or prolonged operation periods. It ensures specimen integrity during sectioning, particularly when working within the temperature range of -10C to +50C as specified for the device.

Q: Where is the Fully Automatic Microtome Model FAMT-2024 typically used?

A: This model is ideal for laboratory environments such as histology, pathology, and research institutes requiring high-throughput, precise tissue sectioning. Its robust design allows seamless integration into facilities within the operating humidity range of 10%%80%%.

Q: What are the benefits of the universal blade holder with lateral displacement?

A: The blade holder accommodates various blade types and allows lateral adjustment to maximize blade usage and maintain consistent cutting quality. This reduces downtime and material waste, supporting efficient workflow and cost-effectiveness.

Q: How do I operate the emergency stop function for immediate machine shutdown?

A: In case of emergencies, pressing the designated emergency stop button will immediately halt microtome operations, ensuring user safety and protecting both the specimen and equipment from inadvertent errors.

Q: What usage capacity and accuracy does this microtome guarantee?

A: The FAMT-2024 is rated for up to 250300 specimen blocks per day and delivers 100%% accuracy in section thickness due to its precision rotary blade holder and advanced microprocessor control, supporting reliable and reproducible results in every session.
