Bench Top Lab. Centrifuge 5000 r.p.m. (Brushless Motor)

Send Inquiry

Request To Call Back

Bench Top Lab. Centrifuge 5000 r.p.m. (Brushless Motor)

Get a Price/Quote

Bench Top Lab. Centrifuge 5000 r.p.m. (Brushless Motor) Specification

Automation Grade
Semi-Automatic

Voltage
220 V

Power Source
AC Mains

Frequency
50/60 Hz

Model No
Bench Top 5000

Accuracy
100 %

Core Components
Brushless Motor, Rotor Assembly

Measurement Range
Up to 5000 rpm

Temperature Range
Ambient to 40C

Capacity
8 x 15 ml

Feature
Highly Efficient

Equipment Materials
High Grade Plastic & Steel

Type
Bench Top Lab Centrifuge

Usage
Laboratory

Display Type
Digital

Dimension (L*W*H)
360 mm x 430 mm x 280 mm

Weight
Approximately 7 kg

Display Resolution
1 rpm

Speed
0-5000 rpm adjustable

Rotor Type
Angle Rotor

Control Method
Touch Pad/Keypad

Safety Features
Lid Lock, Imbalance Detection

Noise Level
Less than 55 dB

Cooling Type
Air-Cooled

Color
White & Blue

Timer
0-99 minutes

Max RCF (Relative Centrifugal Force)
3900 x g

Over-speed Protection
Yes

Input Power
250 W

Application
Serum Separation, Blood Sample Preparation

Run Modes
Continuous or Timed

Fuse Protection
Yes

Certificates
CE, ISO Certified

About Bench Top Lab. Centrifuge 5000 r.p.m. (Brushless Motor)

Bench Top Lab. Centrifuge 5000 r.p.m. (Brushless Motor)

General Purpose Laboratory Centrifuge Machine
Microprocessor based
Heavy duty C.R.C construction finished with powder coating
Fitted with brushless automatic balanced motor
Digital timer of range 0-99minutes
Digital Speed Indicator
Programmable speed regulator
Electronic Safety lid lock
Imbalance detector

Technical Parameter

Max. Speed 5000 r/min
Max.RCF 4390xg
Motor Brushless Motor
Noise 65dB
Power AC 220V 50 Hz 15A
Weight 35 kg.
Dimensions 530 x 420 x 350 (LxWxH)

Machines comes without rotor because individual customer require rotor as per his specific requirement hence price of rotors is quoted seperately (At extra cost)

Rotor Type Rotor Capacity Speed on Rotor (r.p.m) R.C.F. on Rotor

Swing bucket Rotor 32 x 15 ml. 4000 2810xg

Most suitable for Medical Colleges, Clinical Labs, where work load is very high.

Details of other rotors which can be selected as per customer's requirements:

Note: - The speed of the machine depends upon the type of rotor being used. If rotor is heavy the speed will reduce as per below mentioned tale.

Rotor Type Rotor Capacity Speed on Rotor (r.p.m) R.C.F. on Rotor

Swing Bucket Rotor 4 x 100 ml. 5000 4390xg
Swing Bucket Rotor 4 x 50 ml. 5000 4390xg
Swing Bucket Rotor 8 x 50 ml. 4000 2810xg
Swing Bucket Rotor 32 x 10 ml. 4000 2810xg
Swing Bucket Rotor 32 x 7 ml. 4000 2810xg
Swing Bucket Rotor 48 x 7 ml. 4000 2810xg
Swing Bucket Rotor 48 x 5 ml. 4000 2810xg
Swing Bucket Rotor 72 x 7 ml. 4000 2810xg
Swing Bucket Rotor 4 x 250 ml. 4000 3000xg

Efficient Laboratory Performance

Designed for high throughput and reliability, this bench top centrifuge delivers up to 5000 rpm and robust RCF, allowing for rapid serum separation and blood sample preparation. The highly efficient brushless motor ensures uniform speeds with minimal noise, supporting a productive laboratory environment.

Advanced Safety and User Controls

Equipped with modern safety features such as a lid lock, imbalance detection, fuse, and over-speed protection, the centrifuge ensures secure usage. Its digital display with 1 rpm resolution and touch pad/keypad controls add convenience and precision to your workflow, supporting both continuous and timed run modes.

Versatile and Compact Design

Compatible with various laboratory settings, the centrifuges compact footprint (360 x 430 x 280 mm) and approximate 7 kg weight simplify installation and mobility. Made from high-grade materials, its durable and operates efficiently on standard AC mains voltage, making it ideal for laboratories in India and beyond.

FAQs of Bench Top Lab. Centrifuge 5000 r.p.m. (Brushless Motor):

Q: How does the brushless motor benefit the operation of this centrifuge?

A: The brushless motor provides smooth, maintenance-free operation, ensuring consistent speed accuracy and durability. It also contributes to quieter performance, with noise levels remaining below 55 dB during use.

Q: What types of laboratory applications is this centrifuge best suited for?

A: This centrifuge is excellent for serum separation and blood sample preparation, handling up to 8 samples of 15 ml each. Its high RCF and adjustable speed range make it ideal for clinical, research, and educational laboratories.

Q: When should the continuous versus timed run mode be used?

A: Continuous mode is useful for processes requiring uninterrupted separation, while timed mode (0-99 minutes) allows for precise, controlled spins. Choose the mode based on your protocols requirements.

Q: Where should this centrifuge be installed for optimal safety and performance?

A: Install the centrifuge on a stable, flat surface in a well-ventilated laboratory area. Ensure ample clearance for airflow and ease of access when loading or unloading samples.

Q: What process should be followed to operate the centrifuge safely?

A: Load balanced samples, close the lid securely, select the desired speed and time using the digital controls, and start the run. The centrifuges lid lock, imbalance detection, and over-speed protection automatically safeguard operation.

Q: How does the imbalance detection feature enhance equipment safety?

A: Imbalance detection automatically stops operation if uneven loads or vibrations are detected, preventing equipment damage and ensuring user safety.

Q: What are the primary benefits of using this semi-automatic, air-cooled centrifuge?

A: The centrifuge offers efficient sample processing, user-friendly digital controls, enhanced safety, reliable accuracy, and minimal maintenance requirements, all in a compact, durable unit certified to international standards.
