B.o.d. Incubator

Get a Price/Quote

B.o.d. Incubator Specification

Core Components
Compressor, Microprocessor Controller, Heater

Voltage
220 V AC

Frequency
50 Hz

Temperature Range
5C to 60C

Automation Grade
Automatic

Feature
Highly Efficient

Capacity
250 L

Accuracy
100 %

Power Source
Electric

Measurement Range
5C to 60C

Model No
BOD-250

Equipment Materials
Stainless Steel Inner Chamber, Powder Coated Outer Body

Type
B.O.D. Incubator

Usage
Laboratory

Display Type
Digital

Dimension (L*W*H)
55 cm x 55 cm x 90 cm

Weight
75 kg

Chamber Illumination
Provided

Door Type
Double Walled with Insulated Glass Window

Cooling System
Hermetically Sealed Compressor

Power Consumption
900 W

Safety Features
Over Temperature Alarm, Fuse Protection

Shelves Material
Stainless Steel

Temperature Control
Digital PID Controller

No. of Shelves
3

About B.o.d. Incubator

B.O.D Incubator are suitable for preservation of vaccines, insulin, lever extracts, chemicals etc. and to make biochemical oxygen demand determination.

Construction : The low temperature incubator is made of double walled M.S sheet finished with epoxy based powder coated paint, inner chamber is made of highly polished stainless steel / anodized aluminium. Two doors are provided. Inner door is made of transparent acrylic for inspecting specimens outer door is insulated and is fitted with magnetic tape with lock and key. Temperature range from 5°C to 50°C with an accuracy of +1°C provided with two air circulating fans, high performance compressor, cooling coils, heating elements. Digital temperature control and display is also fitted with a door operated illumination and a caster wheel for easy mobility. Model No. SSI/93.

SSI/93/01	Cu. FT. : 6.1 Height mm : 825 Width mm : 505 Depth mm : 415 Inner chamber : Aluminium
SSI/93/02	Cu. FT. : 6.1 Height mm : 825 Width mm : 505 Depth mm : 415 Inner chamber : S.S
SSI/93/03	Cu. FT. : 8 Height mm : 850 Width mm : 600 Depth mm : 500 Inner chamber : Aluminium
SSI/93/04	Cu. FT. : 8 Height mm : 850 Width mm : 600 Depth mm : 500 Inner chamber : S.S
SSI/93/05	Cu. FT. : 10 Height mm : 880 Width mm : 550 Depth mm : 550 Inner chamber : Aluminium
SSI/93/06	Cu. FT. : 10 Height mm : 880 Width mm : 550 Depth mm : 550 Inner chamber : S.S.
SSI/93/07	Cu. FT. : 12 Height mm : 900 Width mm : 650 Depth mm : 580 Inner chamber : Aluminium
SSI/93/08	Cu. FT. : 12 Height mm : 900 Width mm : 650 Depth mm : 580 Inner chamber : S.S

B.O.D. Incubator provided with 304 grade stainless steel outer body & digital temperature controller & display. Model No. SSI/93-A

SSI/93-A/01	Cu. FT. : 6.1 Height mm : 825 Width mm : 505 Depth mm : 415
SSI/93-A/02	Cu. FT. : 8 Height mm : 850 Width mm : 600 Depth mm : 500
SSI/93-A/03	Cu. FT. : 10 Height mm : 880 Width mm : 550 Depth mm : 550
SSI/93-A/04	Cu. FT. : 12 Height mm : 900 Width mm : 650 Depth mm : 580

B.O.D. Incubator provided with P.I.D. Controller instead of electronic digital Temperature cum controller at an extra cost. Model No. SSI/93-B

B.O.D. Incubator provided with P.I.D. Controller instend of digital temperature controller and Rs. 232 / Rs. 485 socket for computer attachment you can control the B.O.D through computer. Model No. SSI/93-C

Precise Temperature Regulation

The B.O.D. Incubators advanced digital PID controller guarantees highly accurate temperature control within the 5C to 60C range. The hermetically sealed compressor system ensures uniform cooling, while the chambers stainless steel construction promotes consistent thermal performance. This reliability is essential for sensitive laboratory processes.

Enhanced Observation and Usability

Designed with a double-walled door featuring an insulated glass window, the incubator allows safe monitoring of specimens without temperature disruption. Internal illumination of the chamber further improves ease of observation, making it convenient for users to check progress without opening the door frequently.

Safety and Efficiency Features

User safety is prioritized through features like an over-temperature alarm and fuse protection. Stainless steel shelves offer hygienic storage, and a powder-coated outer body ensures durability. The automatic operation minimizes human oversight, while the digital display facilitates real-time monitoring of operating parameters.

FAQs of B.o.d. Incubator:

Q: How does the B.O.D. Incubator maintain precise temperature control?

A: The incubator uses a digital PID controller and a hermetically sealed compressor system to maintain stable temperatures in the 5C to 60C range. This ensures accurate and consistent conditions crucial for sensitive laboratory processes.

Q: What are the main benefits of the double-walled door with insulated glass window?

A: The double-walled door, equipped with an insulated glass window, allows users to observe specimens without opening the chamber, thus preserving internal conditions and improving specimen safety. This design also helps maintain thermal efficiency.

Q: When is it recommended to use the over-temperature alarm and safety features?

A: The over-temperature alarm and fuse protection are engaged automatically whenever temperature thresholds are exceeded or electrical anomalies occur. These features safeguard stored samples and the equipment itself during unexpected conditions.

Q: Where can the B.O.D. Incubator be utilized?

A: This model is suitable for various laboratory settings across research facilities, universities, pharmaceutical companies, and industrial labs throughout India. Its robust design supports microbiological, environmental, and biochemical studies.

Q: What is the process for cleaning and maintaining the B.O.D. Incubator?

A: Routine maintenance includes wiping stainless steel shelves and chamber surfaces with appropriate disinfectants. The powder-coated outer body can be cleaned with a damp cloth. Regular calibration of the PID controller and checking the fuse improves longevity and performance.

Q: How does the digital display assist in operation?

A: The incubators digital display offers real-time readings of the chambers temperature and controller settings, providing users with immediate feedback and allowing precise adjustments as needed during experiments.
